Description
Capacity 650 to 1440 liters – Loads up to 3000 kgQualities
- Tipper Reinforced tipper for flat waste, specially designed for skeletons and slab scrap.
- Reduced height adapted to the workstation.
- Two triggers as standard :
- automatic by touch: no manual intervention required
- by manual lever
- End of stroke cushioned by rubber stops.
- Two safety latches to prevent accidental release
- Safety link welded to frame.
- Removable feet as standard.
- Maintenance-free equipment.
Features
- Mechanically welded tank sides in thick sheet metal. 3 mm.
- Thick bottom plate
4 mm reinforced by 4 plates on field th.
8 mm. - Continuous, reinforced outer weld at inner corners.
- Bowl edges reinforced by double folding.
- Thick gripping sleeves 5 mm.
- Articulation on Ø 23 mm axle.
- Paint finish: choice of 10 shades.
Options
- Wheels, net, tarpaulin, stainless steel, markings, special sheaths, hot-dip galvanizing
- For other specific requirements, please contact us.
Click here to see a video of our reinforced tipping body for flat waste.
